novAA 800 Series The Routine Analyzer
- Cost-effective – top performance at low investment and operating costs
- Simple – easy handling thanks to user-friendly concepts
- Reliable – stable measuring conditions due to robust components and clever design
- Powerful – high throughput due to integrated sampling and dilution
novAA 800 is the reliable all-rounder, making routine analysis of diverse samples efficient and cost-effective.
The Efficient Workhorse for Your Lab
novAA 800 is the perfect AAS for routine use in industrial QC laboratories and analytical service providers. It combines versatility, reliability, and automation, making it a highly efficient and cost-effective.
- AAS applications - flame, graphite furnace, and hydride technology – all on one small footprint platform
- Simplest operations with high safety standards thanks to intelligent workflows
- Efficient analysis with a high degree of automation and performance-enhancing accessories
- Reliable with latest SiOSens solid state detector and a 10-year long-term warranty on optical components
Brochures
| Title | Language | Info |
|---|---|---|
| Brochure novAA800 series (DE) | de | PDF, 448 KB |
| Brochure novAA800 series (EN) | en | PDF, 439 KB |
| Produktkatalog Chemische Analyse (DE) | de | PDF, 909 KB |
| Product Guide Chemical Analysis (EN) | en | PDF, 886 KB |
| Flyer Calibration Standard Offering for TOC, AAS, and ICP Devices (EN) | en | PDF, 492 KB |
| Flyer Kalibrierstandards für TOC-, AAS- und ICP-Geräte (DE) | de | PDF, 633 KB |
| Flyer Analyse élémentaire des déchets (FR) | fr | PDF, 960 KB |
The Reliable Allrounder
The novAA 800 series is a family of small footprint benchtop atomic absorption spectrometers for highest efficiency in routine analysis. They cover the complete range of AAS applications from elemental contents in %- range up to trace determination. Flame to graphite furnace to hydride mode are combined on one instrumental platform. The dual atomizer concepts with swivel mounted atomizers and automatic alignment simplifies operation. The systems convince with an integrated carousel with RFID reader for 8 coded hollow cathode lamps, deuterium background correction, a proven optical bench in single and double beam mode as well as in emission mode and with the latest SiOSens solid state detector. A wide range of intelligent accessories maximize productivity, safety and ease of use for analytical routines. The combination of clever technology that is made in Germany with pre-programmed software routines offers a very user-friendly overall concept.
- High throughput thanks to integrated sampling and dilution
- Easy handling with user friendly concepts
- High performance at low investment and running cost
- Stable measurement conditions thanks to robust components and a clever design
Products
novAA 800 D - Flame- and Graphite Furnace AAS
AAS for flame, graphite furnace, and hydride technology
The all-rounder with an automatic atomizer change for flame, hydride, and graphite furnace technology, for routine laboratories with changing requirement.
Order number: 812-08002-2
novAA 800 F - Flame AAS
AAS for flame and hydride technology
The flame AAS for the cost-effective and efficient routine analysis of elements across a wide range of applications.
Order number: 812-08000-2
novAA 800 G - Graphite Furnace AAS
AAS for graphite furnace and hydride technology
Cost-effective trace analyzer for recurring measurement tasks.
Order number: 812-08001-2
Applications
Applications
-
Quantifizierung von Hauptbestanteilen in Baustoffen mittels Flammen-AAS (DE)
-
Determination of Major Elements in Building Materials Using Flame AAS (EN)
Applications
-
Reliable high throughput routine analysis (EN)
-
Determination of Toxic and Eco toxic Elements in Sewage Sludges with Flame (EN)
-
Bestimmung von toxischen und ökotoxischen Elementen in Klärschlamm (DE)
-
Quantifizierung von Cadmium, Chrom, Cobalt, Kupfer, Blei, Mangan, Nickel und Zink in Boden und Klärschlamm nach DIN ISO 11047 mittels LS-AAS (DE)
-
Quantification of Cadmium, Chromium, Cobalt, Copper, Lead, Manganese, Nickel, and Zinc in Soil and Sludge in Accordance with DIN ISO 11047 Using LS-AAS (EN)
-
Determination of Major Elements in Building Materials Using Flame AAS (EN)
Applications
-
Quantification of diverse elements ranging from high levels down to trace range (EN)
Applications
-
Copper Quantification in Geological Samples by Flame-AAS (EN)
-
Quantification du cuivre dans des échantillons géologiques par SAA flamme (FR)
-
Copper Quantification in Geological Samples by Flame-AAS (DE)
Applications
-
Quantification of Copper Traces in Jet Fuel according to ASTM D 6732-4 (EN)
-
ASTM D 6732-04に準拠したジェット燃料中の銅の微量分析 (JP)
Technical Data
Detector |
Wavelength precision |
Optical design |
Background correction |
Wavelength range |
Spectral bandwidth |
Light source |
Sensitivity |
Dimension (width x depth x height) |
Space requirement (width x depth x height) |
|
|---|---|---|---|---|---|---|---|---|---|---|
|
novAA 800 D - Flame- and Graphite Furnace AAS |
SiOSens | 0.005 nm | Czerny Turner Spectrometer | Deuterium | 185-900 nm | 0.2, 0.3, 0.5, 0.8, 1.2 nm | Hollow Cathode Lamps (HCL) |
Flame: 0.017 mg/L 1 %Abs (Cu 324) Graphite furnace: 0.79 µg/L 1 %Abs (Pb 283) |
820 mm x 770 mm x 600 mm | |
|
novAA 800 F - Flame AAS |
SiOSens | 0.005 nm | Czerny Turner Spectrometer | Deuterium | 185-900 nm | 0.2, 0.3, 0.5, 0.8, 1.2 nm | Hollow Cathode Lamps (HCL) | Flame: 0.017 mg/L 1 %Abs (Cu 324) | 820 mm x 770 mm x 600 mm | 820 mm x 770 mm x 600 mm |
|
novAA 800 G - Graphite Furnace AAS |
SiOSens | 0.005 nm | Czerny Turner Spectrometer | Deuterium | 185-900 nm | 0.2, 0.3, 0.5, 0.8, 1.2 nm | Hollow Cathode Lamps (HCL) | Graphite furnace: 0.79 µg/L 1 %Abs (Pb 283) | 820 mm x 770 mm x 600 mm | 820 mm x 700 mm x 600 mm |
For more information about our products and possible variants, please refer to the technical documents or use our contact form.
Standards
- BS EN 15488
- DIN 38405-35
- DIN 38406-32
- DIN 38406-33
- DIN 51429-1
- DIN EN 1233
- DIN EN 13131
- DIN EN 14083
- DIN EN 14109
- DIN EN 14332
- DIN EN 241
- DIN EN ISO 11212-3
- DIN EN ISO 11212-4
- DIN EN ISO 12193
- DIN EN ISO 15586
- DIN EN ISO 5961
- DIN EN ISO 7980
- DIN EN ISO 8294
- DIN ISO 11047
- DIN ISO 16772
Order Information
Order number |
Description |
|---|---|
| 812-08002-2 | novAA 800 D Flame and Graphite Furnace AAS |
| 812-08000-2 | novAA 800 F Flame AAS |
| 812-08001-2 | novAA 800 G Graphite Furnace AAS novAA 800G |
Accessories
| Burner head AC (100 mm) for higher sensitivity in the acetylene/ air flame | 810-60056-0 |
| Burner head LPG (100 mm) for operation with LPG flame | 810-60059-0 |
| Burner head NO/AC (50 mm) for acetylene/nitrous-oxide or acetylene/air flame | 810-60057-0 |
| AS-F Autosampler for flame, hydride AAS and CV-AAS/AFS | 810-60500-0 |
| AS-FD Autosampler with auto-dilution for flame, hydride AAS and CV-AAS/AFS | 810-60501-0 |
| Sample rack 139 positions for AS-F and AS-FD | 810-60503-0 |
| Sample rack 54 positions for AS-F and AS-FD | 810-60502-0 |
| Burner fork - for fast replacement of burner heads | 810-60058-0 |
| Scraper - for automatic burner head cleaning | 810-60127-0 |
| Segmented Flow Star SFS 6.0 - switching valve | 810-60129-0 |
| Hg/Hydride System HS 50 - Manual hydride system with flame heated quartz cell atomizer | 810-60149-2 |
| Chiller, 50 Hz - Software-controlled cooling system | 810-60053-0 |
| Chiller, 60 Hz - Software-controlled cooling system | 810-60052-0 |
| Air purge kit (APK) for novAA 800 series | 810-60506-0 |
| Air compressor, 50/60Hz, 230V - to supply AAS with water- and oil- free compressed air | 810-60055-0 |
| Hg/Hydride System HS 60 - Flow injection system for Hg and hydride forming elements | 810-60402-2 |
| Hg/Hydrid-System HS 55 - Batch mode system for Hg and hydride forming elements | 810-60404-2 |
| Bench for ICP/AAS for AAS, ICP-OES and ICP-MS instrumentation | 810-88005-0 |
| AS-GF Autosampler for graphite furnace AAS | 810-60510-0 |
| Air compressor, 50/60Hz, 110V - to supply AAS with water- and oil- free compressed air | 810-60276-0 |
Software
ASpect LS
Simple, routine handling provided via a single user interface featuring great flexibility – the Aspect LS is a modern and intuitive software with fully automatic device control and extensive data evaluation function. Software functions and modules help to meet all legal requirements and standards.
- Quickstart – no expert knowledge required
- Ready-to-use worksheets for outstanding usability
- Simple methode development
- Comprehensive evaluation function
- Good laboratory practice (GLP): Control charts for statistical quality control along with notifications whenever defined limit values are exceeded – to maintain comprehensive quality
- FDA 21 CFR Part 11 Compliance (optional)
| Product | Required | Included |
|---|---|---|
| novAA 800 D - Flame- and Graphite Furnace AAS (812-08002-2) | ||
| novAA 800 F - Flame AAS (812-08000-2) | ||
| novAA 800 G - Graphite Furnace AAS (812-08001-2) |
FDA 21 CFR Part 11 Compliance for ASpect LS
Order number: 810-60152-0
The ASpect LS software with the FDA 21 CFR Part 11 module fully complies with FDA requirements. User rights management and individual passwords ensure that the system can only be accessed by authorized persons. All important events, such as logon/logoff, measurements, calibrations, and messages generated by the Self Check System, are recorded in the Audit Trail. Measured data can undergo routine review and approval using electronic signatures.
| Product | Required | Included |
|---|---|---|
| novAA 800 D - Flame- and Graphite Furnace AAS (812-08002-2) | ||
| novAA 800 F - Flame AAS (812-08000-2) | ||
| novAA 800 G - Graphite Furnace AAS (812-08001-2) |
Consumables
| 810-60258-0 | Consumable set F for Flame technique novAA/contrAA/ZEEnit series |
| 810-60066-0 | Consumable set G for graphite technique novAA/contrAA |
| 407-A81.020 | Graphite pipetting insert for novAA / contrAA series |
| 407-A81.025 | Graphite tube - PIN platform - pyrolytically coated |
| 407-A81.011 | Graphite tubes - pyrolytically coated |
| 407-A81.021 | Ceramic O-rings for furnace |
| 702-A63.624 | Cleaning strips for flame AAS |
| 702-A63.625 | Cleaning wires for flame AAS |
| 407-111.860 | Impact bead (standard, short) for mixing chamber (black, Ryton)-nebulizer (graphite)-system (III) |
| 407-111.006 | Inlet tube (PTFE), manual work for mixing chamber (black, Ryton)-nebulizer (graphite )-system (III) |
| 407-111.501 | Nebulizer for mixing chamber(black)-nebulizer-system (III) |
| 407-111.402 | Set o-rings organic samples for mixing chamber (black)-nebulizer-system (III) |
| 407-143.021 | Set sealing rings for mixing chamber (black, Ryton)-nebulizer (graphite)-system (III) |
| 407-111.837 | Waste tube siphon for mixing chamber (black, Ryton)-nebulizer (graphite)-system (III) |
| 407-1508.108 | Level sensor, organic samples for mixing chamber (black)-nebulizer-system (III) |
| 810-60508-0 | Consumables Set H for Hydride Systems |
